Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| TRACK SP D95 55 W 3000 K 90RA NFL WT | 55.00 W | 50000 | 24 ° | 4000 lm | No |
| TRACK SP D95 55 W 3000 K 90RA NFL GY | 55.00 W | 50000 | 24 ° | 4000 lm | No |
| TRACK SP D95 55 W 3000 K 90RA NFL BK | 55.00 W | 50000 | 24 ° | 4000 lm | No |
| TRACK SP D95 55 W 4000 K 90RA NFL BK | 55.00 W | 50000 | 24 ° | 4200 lm | No |
| TRACK SP D95 55 W 4000 K 90RA NFL WT | 55.00 W | 50000 | 24 ° | 4200 lm | No |
| TRACK SP D95 55 W 4000 K 90RA NFL GY | 55.00 W | 50000 | 24 ° | 4200 lm | No |
| Nominal wattage | 55.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 240 mA |
| Inrush current |
|
| Inrush current time Th50 | < 5 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 32 |
| Max. number of luminaires per miniature circuit breaker C10 | 26 |
| Max. number of luminaires per miniature circuit breaker C16 | 41 |
| Power factor λ | ≥0.90 |
| Total harmonic distortion | < 15 % |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Luminous flux | 4000 lm |
| Luminous efficacy | 70 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | 90 |
| Standard deviation of color matching | ≤3 sdcm |
| Luminous intensity | - |
| Low flicker | Yes |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 24 ° |
| Diameter | 95.00 mm |
| Height | 297.00 mm |
| Product weight | 1520.00 g |
| Product color | White |
| Housing color | White |
| Body material | Aluminum |
| Cover material | Polymethylmethacrylate (PMMA) |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Type of connection | Adapter, 3-phase |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK02 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Mounting track |
| Application environment | Indoor |
| Adjustable | Yes |
| Replaceable light source | No |
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
| Lifespan L80/B10 at 25 °C | 45000 h 1) |
| Lifespan L90/B10 at 25 °C | 30000 h |
| Number of switching cycles | 50000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Output current | 1300 mA |
| ECG - Output ripple current | < 10 % |
| Standards | CE, CB, ENEC, TÜV SÜD, EAC, RoHS |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075113527 | Folding box 1 |
120 mm x 120 mm x 330 mm | 1625.00 g | 4.75 dm³ |
| 4058075113534 | Shipping box 4 |
495 mm x 130 mm x 340 mm | 6977.00 g | 21.88 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4058075113527 | 7402087 | 4231947 | 3201953 | 941600140 |
