Choose your product version
| Nominal wattage | 14.40 W |
| Construction wattage | 14.40 W |
| Nominal wattage per meter | 14,4 W |
| Nominal voltage | 24 V |
| Type of current | DC |
| Luminous flux per meter | 370 lm |
| Light color (designation) | RGB |
| Beam angle | 120 ° |
| Number of LEDs per meter | 60 |
| Length | 1000.00 mm |
| Width | 16.00 mm |
| Height | 16.00 mm |
| Prewired | Yes |
| Product weight | 150.00 g |
| Ambient temperature range | -20…+45 °C |
| Maximum temperature at tc test point | 75 °C |
| Nominal lamp life time | 40000 h |
| Number of switching cycles | 100000 |
| Dimmable | Yes |
| Lowest bending radius | 30 mm |
| Self-adhesive | Yes |
| Type of protection | IP65 |
| Temperature range at storage | -20…+80 °C |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075362833 | BAG 1 |
507.00 g | ||
| 4058075362840 | Shipping box 10 |
1,060 mm x 35 mm x 33 mm | 1554.00 g | 1.22 dm³ |
| 4058075362857 | Shipping box 60 |
1,070 mm x 110 mm x 90 mm | 9583.00 g | 10.59 dm³ |
| Product image | Product name | EAN |
|---|---|---|
|
MS-CV-DIM RF 12/24 V RGB | 4058075359789 |
|
MS-CV-DIM RF 12/24 V RGB RM | 4058075359826 |
