Choose your product version
| Nominal wattage | 20.00 W |
| Nominal output power | 11.9…21.0 W |
| Nominal voltage | 220…240 V |
| Nominal output voltage | 25…40 V |
| Input voltage AC | 198…264 V 1) |
| Nominal output current | 500 mA |
| Inrush current | < 10 A |
| Output current tolerance | ±5 % |
| Mains frequency | 50…60 Hz |
| Total harmonic distortion | < 10 % |
| Power factor λ | ≥0.90 2) |
| ECG efficiency | ≧84 % 3) |
| Galvanic isolation | SELV |
1) Permitted voltage range
2) Full load at 230 V
3) At full load, 230 V, 50 Hz
| Length | 115.00 mm |
| Width | 45.00 mm |
| Height | 28.00 mm |
| Product weight | 60.00 g |
| Product color | White |
| Body material | Plastic |
| Ambient temperature range | -20…+45 °C |
| Max.housing temperature in case of fault | 110 °C |
| Temperature range in operation | -20…+45 °C |
| Permitted rel. humidity during operation | 5…85 % |
| ECG lifetime | 50000 h 1) |
1) At Ta = 45°C / Tc = 80°C / 10% failure rate
| Dimmable | No |
| Overheating protection | No |
| Overload protection | Automatic reversible |
| Short-circuit protection | Automatic reversible |
| Max. cable length to lamp/LED module | 2,0 m |
| Suitable for emergency lighting | No |
| Approval marks – approval | CB, RoHS |
| Protection class | II |
| Type of protection | IP20 |
| Temperature range at storage | -25…+85 °C |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075463639 | Unpacked 1 |
|||
| 4058075463646 | Shipping box 100 |
465 mm x 160 mm x 250 mm | 10200.00 g | 18.60 dm³ |
