Choose your product version
| Product description |
|---|
| DRIVER CC PROFESSIONAL 20W 800mA 220-240V |
| DRIVER CC PROFESSIONAL 40W 1050mA 220-240V |
| Nominal wattage | 40.00 W |
| Nominal voltage | 220…240 V |
| U-OUT (working voltage) | 55 V |
| Type of current | DC |
| Nominal current | 750…1050 mA |
| Output current tolerance | +/- 5 % |
| Output ripple current (100 Hz) | < 5 % |
| Mains frequency | 50…60 Hz |
| Total harmonic distortion | < 10 % |
| Power factor λ | > 0.95 |
| ECG efficiency | > 85 |
| Device power loss | 7 W |
| Surge capability (L-N) | 1 kV |
| Length | 170.00 mm |
| Width | 37.00 mm |
| Height | 30.00 mm |
| Product weight | 158.00 g |
| Product color | White |
| Body material | Plastic |
| Ambient temperature range | -20…+45 °C |
| Maximum temperature at tc test point | 90 °C |
| Dimmable | Yes |
| Dimming range | 5...100 % |
| Overload protection | Yes |
| Short-circuit protection | Yes |
| Protection class | II |
| Type of protection | IP20 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075707450 | Unpacked 1 |
|||
| 4058075707467 | Shipping box 24 |
362 mm x 207 mm x 173 mm | 4110.00 g | 12.96 dm³ |
