Choose your product version
| Nominal wattage | 34.50 W |
| Nominal output power | 30 W |
| Nominal voltage | 220…240 V |
| Nominal output voltage | 25…42 V |
| Nominal output current | 450 mA, 500 mA, 550 mA, 600 mA, 650 mA, 700 mA |
| Output current tolerance | ±7,5 % |
| Output ripple current (100 Hz) | < 5 % |
| Mains frequency | 50…60 Hz |
| Total harmonic distortion | 20 % |
| Power factor λ | 0.90 |
| Surge capability (L-N) | 1 kV |
| Galvanic isolation | SELV |
| Length | 97.00 mm |
| Width | 40.00 mm |
| Height | 27.00 mm |
| Product weight | 117.00 g |
| Casing material | Plastic |
| Body material | Plastic |
| Ambient temperature range | -20…+50 °C |
| Maximum temperature at tc test point | 80 °C |
| Max.housing temperature in case of fault | 110 °C |
| Temperature range in operation | -20…+50 °C |
| Dimmable | Yes |
| Dimming interface | Phase Cut |
| Overload protection | Yes |
| Short-circuit protection | Yes |
| No-load proof | Yes |
| Approval marks – approval | CE, RoHS |
| Standards | Acc. to IEC 61347-1, Acc. to IEC 61347-2-13, Acc. to EN 55015, Acc. to IEC 61547, Acc. to IEC 61000 |
| Protection class | II |
| Type of protection | IP20 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075299757 | Unpacked 1 |
36 mm x 26 mm x 89 mm | 84.00 g | 0.08 dm³ |
| 4058075299764 | Shipping box 40 |
218 mm x 212 mm x 152 mm | 5848.00 g | 7.02 dm³ |
