Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| NAV-E 50 W/I E27 | E27 | 50 W | 85 V | 24000 h | 3700 lm | No |
| NAV-E 70 W/I E27 | E27 | 70 W | 90 V | 24000 h | 5900 lm | No |
| Nominal wattage | 70 W |
| Construction wattage | 74.60 W |
| Nominal voltage | 90 V |
| Ignition voltage | 0.198 kVp |
| Operating mode | Conventional control gear (CCG) without ignitor, Electronic control gear (ECG) |
| Nominal current | 980 mA |
| PFC capacitor at 50 Hz | 12 µF |
| Luminous flux | 5900 lm |
| Luminous efficacy | 79 lm/W |
| Color temperature | 2000 K |
| Color rendering index Ra | ≤25 |
| Light color | 220 |
| Rated LLMF at 2,000 h | 0.92 |
| Rated LLMF at 4,000 h | 0.86 |
| Rated LLMF at 6,000 h | 0.83 |
| Rated LLMF at 8,000 h | 0.82 |
| Rated LLMF at 12,000 h | 0.81 |
| Rated LLMF at 16,000 h | 0.81 |
| Rated LLMF at 20,000 h | 0.80 |
| UV protection | No |
| Overall length | 155.00 mm |
| Diameter | 71 mm |
| Product weight | 50.00 g |
| Maximum permitted outer bulb temperature | 310 °C |
| Maximum permitted base edge temperature | 210 °C |
| Rated lamp survival factor at 2,000 h | 0.98 |
| Rated lamp survival factor at 4,000 h | 0.97 |
| Rated lamp survival factor at 6,000 h | 0.97 |
| Rated lamp survival factor at 8,000 h | 0.60 |
| Rated lamp survival factor at 12,000 h | 0.95 |
| Rated lamp survival factor at 16,000 | 0.85 |
| Rated lamp survival factor at 20,000 h | 0.70 |
| Lifespan B10 | 14000 h |
| Lifespan B5 | 12000 h |
| Lifespan B50 | 24000 h |
| Base (standard designation) | E27 |
| Mercury content | 10.8 mg |
| Design / version | Coated |
| Product remark | Operate only with NAV control gear. No igniter required |
| Dimmable | No |
| Burning position | Any |
| Enclosed luminaire required | No |
| Energy efficiency class | G |
| Energy consumption | 75.00 kWh/1000h |
| ILCOS | SE-70-H/I/S-E27-71/156 |
| Order reference | NAV-E 70W/I E27 |
| Lighting technology used | HPS |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | E27 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | SECOND |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 155.00 mm |
| Height | 71 mm |
| Width | 71 mm |
| Chromaticity coordinate x | 0,535 |
| Chromaticity coordinate y | 0,420 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546572 |
| Model number | AC34364,AC34364 |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300015590 | Round wrap 1 |
75 mm x 75 mm x 165 mm | 83.00 g | 0.93 dm³ |
| 4050300221250 | Shipping box 24 |
360 mm x 285 mm x 355 mm | 2039.00 g | 36.42 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number | AU model number |
|---|---|---|---|---|---|
| 4050300015590 | 8331704 | 4835551 | 3852148 | 948620190 | OSRNAV-E70/I |
